CALTERM AUTOMOTIVE TEST METER WITH INDUCTIVE PICK UP
ITEM NO: 66474
Features and Benefits:
Diagnostic Functions:
1. DC VOLTAGE , Test starter,Alternator,Batteries,and Sensor.
200mvolts,2 volts,20 volts, 200 volts, accuracy +- 0.5%
2.AC VOLTAGE, Test Garage Circuits,Electrical motors and wiring
200 Volts, 750 Volts, accuracy: +- 1.2%
3.OHMS,Check resistance in Sensors,injectors,Plug wires and coils.
200 ohms,2k ohms,20k ohms,200k ohms, 2M ohms, 20M ohms, accuracy: +-.75%to+- 1.0%
3.Temperature: Measure ambient temperature in Fahrenheit or Centigrade.
0F to 2000F, -20C to 1370C accuracy: +-1.5% to +-3.0%
4.Hold,Retains reading on LCD screen for later analysis
5.Points: Detect bad ignition points, and poor ignition connection.
6 HI-TACH Monitor engines speed and set idles 0-12,000rpm
7.LO-TACH Monitor engines speed and set idles 0-2000rpm
8.Frequency,Measures Hertz to check computer controlled sendor.
2K Hz, 20K hz accuracy : +- 2.0%
9.Dwell, Check ignition point gap and test GM-3 fuel system
10.Duty cycle: Check variable signals in computer controlled circuits
11.AUX: Measure up to 400A DC with optional high current adapter
12, It is an old tool on 1994, come with Calterm Serial# and qualty test and Packaged in the USA
Sold as it is
